Anti-Collapse Mesh

Anti Collapse Mesh

The Anti-Collapse System represents a simple yet cost effective method of avoiding many accidents in the storage and handling of pallets in and on racking systems. The framed mesh system is mounted on brackets, which are designed to fit most types of racking systems. The brackets are 100mm and 250mm in length, other sizes can be manufactured to your requirements. The mesh panels are available in Galvanised material but RAL colours can be supplied to order.

The Anti-Collapse brackets are manufactured from 3mm material, formed and in powder coated finished material to match the mesh this then creates a sturdy base to mount the mesh panels on. All nuts and bolts are manufactured from BZP.

The brackets attach directly to most types of Pallet Racking. The mesh can be fitted to a new installation or to existing Pallet Racking. The Anti Collapse mesh is used where the racking runs along walkways or pedestrian areas, and helps protect these from falling objects.

Technical Information

Mesh: Standards 50mm x 50mm, other mesh sizes 25mm x 25mm,
Wire Diameter: 3mm Vertical x 3mm Horizontal
System: Box Section Framed system 20mm x 20mm
Colour: Standard is powder coated Grey other colours available upon request at extra cost.

We offer a full fitting service on all our products.
